Freescale Semiconductor MPC5200B - Page 103

MPC5200B Users Guide, Rev. 1
2-58 Freescale Semiconductor
Pinout Tables
Pin ETH_10 Ball J03
GPIO hi - z GPIO
Simple General Purpose Output
USB2 hi - z GPIO
Simple General Purpose Output
ETH7 Wire hi - z ETH_COL
Ethernet Collision Detect Input
ETH7 Wire / USB2 hi - z ETH_COL
Ethernet Collision Detect Input
ETH18 Wire w/o MD hi - z ETH_COL
Ethernet Collision Detect Input
ETH18 Wire w/ MD hi - z ETH_COL
Ethernet Collision Detect Input
EHT7 Wire, UART4e, J1850 hi - z ETH_COL
Ethernet Collision Detect Input
ETH7 Wire, J1850 hi - z ETH_COL
Ethernet Collision Detect Input
UART_4, UART5e, J1850 hi - z GPIO
Simple General Purpose Output
UART5e, J1850 hi - z GPIO
Simple General Purpose Output
J1850 hi - z GPIO
Simple General Purpose Output
Pin ETH_11 Ball L04
GPIO hi - z GPIO
Simple General Purpose Output
USB2 hi - z GPIO
Simple General Purpose Output
ETH7 Wire hi - z ETH_TXCLK
Ethernet Transmit Clock Input
ETH7 Wire / USB2 hi - z ETH_TXCLK
Ethernet Transmit Clock Input
ETH18 Wire w/o MD hi - z ETH_TXCLK
Ethernet Transmit Clock Input
ETH18 Wire w/ MD hi - z ETH_TXCLK
Ethernet Transmit Clock Input
EHT7 Wire, UART4e, J1850 hi - z ETH_TXCLK
Ethernet Transmit Clock Input
ETH7 Wire, J1850 hi - z ETH_TXCLK
Ethernet Transmit Clock Input
UART_4, UART5e, J1850 hi - z GPIO
Simple General Purpose Output
UART5e, J1850 hi - z GPIO
Simple General Purpose Output
J1850 hi - z GPIO
Simple General Purpose Output
Table 2-21. Ethernet Input / Control Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
