Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-5
A11 PSC1_1 C06 PSC3_3
A12 PSC6_2 C07 PSC3_0
A13 PORRESET C08 CORE_PLL_AVDD
A14 SRESET C09 PSC2_0
A15 SYS_XTAL_IN C10 PSC1_2
A16 MEM_MA_1 C11 PSC6_1
A17 MEM_MBA_1 C12 GPIO_WKUP_7
A18 MEM_RAS C13 PSC6_3
A19 MEM_WE C14 SYS_PLL_AVSS
A20 MEM_DQM_2 C15 GPIO_WKUP_6
B01 TEST_SEL_0 C16 MEM_MA_3
B02 TEST_MODE_0 C17 MEM_MA_0
B03 JTAG_TRST C18 MEM_MBA_0
B04 JTAG_TCK C19 MEM_MA_5
B05 PSC3_7 C20 MEM_MA_6
B06 PSC3_4 D01 TIMER_4
B07 PSC3_1 D02 TIMER_3
B08 PSC2_3 D03 TIMER_2
B09 PSC2_1 D04 VSS_IO/CORE
B10 PSC1_3 D05 VDD_CORE
B11 PSC1_0 D06 VDD_IO
B12 PSC6_0 D07 VDD_CORE
B13 HRESET D08 LP_OE
B14 SYS_PLL_AVDD D09 VDD_IO
B15 SYS_PLL_TPA D10 VDD_CORE
D11 VDD_CORE H04 VDD_IO
D12 VDD_MEM_IO H17 VDD_MEM_IO
D13 VDD_MEM_IO H18 MEM_MDQ_20
D14 SYS_XTAL_OUT H19 MEM_DQM_1
D15 VDD_MEM_IO H20 MEM_MDQS_1
D16 VSS_IO/CORE J01 ETH_3
D17 VDD_MEM_IO J02 ETH_4
D18 MEM_MDQS_2 J03 ETH_10
D19 MEM_MA_7 J04 ETH_17
D20 MEM_MA_8 J09 VSS_IO/CORE
Table 2-1. Signals by Ball/Pin (continued)
Ball/Pin Pin Name Ball/Pin Pin Name
