Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-7
M09 VSS_IO/CORE T18 MEM_MDQ_30
M10 VSS_IO/CORE T19 MEM_MDQ_3
M11 VSS_IO/CORE T20 MEM_MDQ_2
M12 VSS_IO/CORE U01 PCI_REQ
M17 VDD_MEM_IO U02 PCI_IDSEL
M18 MEM_MDQ_24 U03 EXT_AD_24
M19 MEM_MDQ_14 U04 VSS_IO/CORE
M20 MEM_MDQ_15 U05 VDD_IO
N01 ETH_7 U06 VDD_IO
N02 ETH_6 U07 VDD_CORE
N03 ETH_15 U08 EXT_AD_15
N04 ETH_14 U09 VDD_IO
N17 MEM_MDQ_25 U10 VDD_IO
N18 MEM_MDQ_26 U11 EXT_AD_6
N19 MEM_DQM_0 U12 VDD_CORE
N20 MEM_MDQS_0 U13 VDD_IO
P01 IRQ1 U14 LP_ACK
P02 IRQ2 U15 VDD_CORE
P03 IRQ0 U16 VDD_IO
P04 VDD_CORE U17 VSS_IO/CORE
P17 VDD_MEM_IO U18 MEM_MDQ_31
P18 MEM_MDQ_27 U19 MEM_MDQ_1
P19 MEM_MDQ_7 U20 MEM_MDQ_0
P20 MEM_MDQ_6 V01 EXT_AD_31
R01 IRQ3 V02 EXT_AD_20
R02 PCI_RESET V03 EXT_AD_22
R03 EXT_AD_30 V04 EXT_AD_18
R04 PCI_GNT V05 PCI_FRAME
R17 MEM_MDQ_28 V06 PCI_STOP
V07 PCI_PAR Y04 EXT_AD_19
V08 EXT_AD_13 Y05 EXT_AD_17
V09 EXT_AD_11 Y06 PCI_IRDY
V10 EXT_AD_9 Y07 PCI_PERR
V11 EXT_AD_4 Y08 PCI_CBE_1
V12 EXT_AD_2 Y09 EXT_AD_12
Table 2-1. Signals by Ball/Pin (continued)
Ball/Pin Pin Name Ball/Pin Pin Name
