I
2
C Interface Registers
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 18-17
18.3.6 I
2
C Interrupt Control Register—MBAR + 0x3D20
The Interrupt Control register is common to both MPC5200B I
2
C modules. Each module generates an internal interrupt that can be routed as
follows:
To the CPU interrupt, if IE is set to 1.
To the TX requestor at SDMA, if TE is set to 1.
Table 18-8. I
2
C Interrupt Control Register
msb 012345678 9 1011121314 15
R
BNBE2
TE2 RE2 IE2
BNBE1
TE1 RE1 IE1 Reserved
W
RESET:0 00100010 0 0 0 00 0 0
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 lsb
R
Reserved
W
RESET:0 00000000 0 0 0 00 0 0
Bit Name Description
0 BNBE2 Bus Not Busy Enable 2—lets module 2 generate an interrupt when the bus is not busy. BNBE2
indicates an idle condition.
To clear the interrupt, software must write 0 to the bit position.
Reset condition disables BNBE2.
1 TE2 Transmit Enable 2—routes the interrupt for module 2 to the TX requestor at SDMA.
Clear by writing 0 to this bit position.
Reset condition disables TE2.
2 RE2 Receive Enable 2—routes the interrupt for module 2 to the RX requestor at SDMA.
Clear by writing 0 to this bit position.
Reset condition disables RE2.
3 IE2 Interrupt Enable 2—routes the interrupt for module 2 to the CPU.
Clear by writing 0 to this bit position.
Reset condition enables IE2.
4 BNBE1 Bus Not Busy Enable 1—lets module 1 generate an interrupt when the bus is not busy. BNBE1
indicates an idle condition.
To clear the interrupt, software must write 0 to the bit position.
Reset condition disables this bit.
5 TE1 Transmit Enable 1—routes the interrupt for module 1 to the TX requestor at SDMA.
Clear by writing 0 to this bit position.
Reset condition disables TE1.
6 RE1 Receive Enable 1—routes the interrupt for module 1 to the RX requestor at SDMA.
Clear by writing a 0 to this bit position.
Reset condition disables RE1.
7 IE1 Interrupt Enable 1—routes the interrupt for module 1 to the CPU.
Clear by writing 0 to this bit position.
Reset condition enables IE1.
8:31 Reserved
