Freescale Semiconductor MPC5200B - Page 70

Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-25
Pin EXT_AD_6 Ball U11
LocalPlus Bus multiplexed mode
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A6
logic 0
logic 0
D6
hi - z
LocalPlus Address Bit A6
logic 0
logic 0
LocalPlus Data Bit D6
LocalPlus non-mux
16-bit addr/16-bit data
24-bit addr/8-bit data
A6
A6
hi - z
LocalPlus Address Bit A6
LocalPlus Address Bit A6
LFLASH A6 hi - z Large Flash Address Bit A6
MOST Graphics D6 hi - z MOST Graphics Data Bit D6
ATA ATA_ DATA_6 h i - z ATA_ DATA_6
PCI
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A6
D6
D6
D6
hi - z
PCI Address Bit A6
PCI Data Bit D6
PCI Data Bit D6
PCI Data Bit D6
Pin EXT_AD_5 Ball W12
LocalPlus Bus multiplexed mode
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A5
logic 0
logic 0
D5
hi - z
LocalPlus Address Bit A5
logic 0
logic 0
LocalPlus Data Bit D5
LocalPlus non-mux
16-bit addr/16-bit data
24-bit addr/8-bit data
A5
A5
hi - z
LocalPlus Address Bit A5
LocalPlus Address Bit A5
LFLASH A5 hi - z Large Flash Address Bit A5
MOST Graphics D5 hi - z MOST Graphics Data Bit D5
ATA ATA_ DATA_5 h i - z ATA_ DATA_5
PCI
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A5
D5
D5
D5
hi - z
PCI Address Bit A5
PCI Data Bit D5
PCI Data Bit D5
PCI Data Bit D5
Pin EXT_AD_4 Ball V11
LocalPlus Bus multiplexed mode
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A4
logic 0
logic 0
D4
hi - z
LocalPlus Address Bit A4
logic 0
logic 0
LocalPlus Data Bit D4
LocalPlus non-mux
16-bit addr/16-bit data
24-bit addr/8-bit data
A4
A4
hi - z
LocalPlus Address Bit A4
LocalPlus Address Bit A4
LFLASH A4 hi - z Large Flash Address Bit A4
MOST Graphics D4 hi - z MOST Graphics Data Bit D4
ATA ATA_ DATA_4 h i - z ATA_ DATA_4
PCI
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A4
D4
D4
D4
hi - z
PCI Address Bit A4
PCI Data Bit D4
PCI Data Bit D4
PCI Data Bit D4
Table 2-5. LocalPlus Bus Address / Data Signals (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
