Freescale Semiconductor MPC5200B - Page 71

MPC5200B Users Guide, Rev. 1
2-26 Freescale Semiconductor
Pinout Tables
Pin EXT_AD_3 Ball Y12
LocalPlus Bus multiplexed mode
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A3
logic 0
logic 0
D3
hi - z
LocalPlus Address Bit A3
logic 0
logic 0
LocalPlus Data Bit D3
LocalPlus non-mux
16-bit addr/16-bit data
24-bit addr/8-bit data
A3
A3
hi - z
LocalPlus Address Bit A3
LocalPlus Address Bit A3
LFLASH A3 hi - z Large Flash Address Bit A3
MOST Graphics D3 hi - z MOST Graphics Data Bit D3
ATA ATA_ DATA_3 h i - z ATA_ DATA_3
PCI
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A3
D3
D3
D3
hi - z
PCI Address Bit A3
PCI Data Bit D3
PCI Data Bit D3
PCI Data Bit D3
Pin EXT_AD_2 Ball V12
LocalPlus Bus multiplexed mode
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A2
logic 0
logic 0
D2
hi - z
LocalPlus Address Bit A2
logic 0
logic 0
LocalPlus Data Bit D2
LocalPlus non-mux
16-bit addr/16-bit data
24-bit addr/8-bit data
A2
A2
hi - z
LocalPlus Address Bit A2
LocalPlus Address Bit A2
LFLASH A2 hi - z Large Flash Address Bit A2
MOST Graphics D2 hi - z MOST Graphics Data Bit D2
ATA ATA_ DATA_2 h i - z ATA_ DATA_2
PCI
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A2
D2
D2
D2
hi - z
PCI Address Bit A2
PCI Data Bit D2
PCI Data Bit D2
PCI Data Bit D2
Pin EXT_AD_1 Ball W13
LocalPlus Bus multiplexed mode
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A1
logic 0
logic 0
D1
hi - z
LocalPlus Address Bit A1
logic 0
logic 0
LocalPlus Data Bit D1
LocalPlus non-mux
16-bit addr/16-bit data
24-bit addr/8-bit data
A1
A1
hi - z
LocalPlus Address Bit A1
LocalPlus Address Bit A1
LFLASH A1 hi - z Large Flash Address Bit A1
MOST Graphics D1 hi - z MOST Graphics Data Bit D1
ATA ATA_ DATA_1 h i - z ATA_ DATA_1
PCI
Address Phase
8-Bit Data Phase
16-Bit Data Phase
32-Bit Data Phase
A1
D1
D1
D1
hi - z
PCI Address Bit A1
PCI Data Bit D1
PCI Data Bit D1
PCI Data Bit D1
Table 2-5. LocalPlus Bus Address / Data Signals (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
