Pinout Tables

MPC5200B Users Guide, Rev. 1

Freescale Semiconductor 2-41

Pin PSC3_5 Ball A06

GPIO hi - z LP_CS_7

USB2 hi - z USB2_RXN

USB Receive Positive

UART3 hi - z LP_CS_7

UART3e hi - z LP_CS_7

CODEC3 hi - z LP_CS_7

CODEC3_w/MCLK hi - z CODEC3_w/MCLK_MCLK

CODEC Clock

SPI hi - z LP_CS_7

UART3, SPI hi - z LP_CS_7

UART3e,SPI hi - z LP_CS_7

CODEC3, SPI hi - z LP_CS_7

Pin PSC3_6 Ball C05

GPIO hi - z GPIO

Simple General Purpose I/O

USB2 hi - z USB2_PRTPWR

USB Port Power

UART3 hi - z GPIO

Simple General Purpose I/O

UART3e hi - z GPIO_

Simple General Purpose I/O

CODEC3 hi - z GPIO

Simple General Purpose I/O

CODEC3_w/MCLK hi - z LP_CS_7

SPI hi - z SPI_MOSI

SPI_Master Out Slave In

UART3, SPI hi - z SPI_MOSI

SPI_Master Out Slave In

UART3e, SPI hi - z SPI_MOSI

SPI_Master Out Slave In

CODEC3, SPI hi - z SPI_MOSI

SPI_Master Out Slave In

Table 2-15. PSC3 Functions by Pin (continued)

PIN / BALL NUMBER Function

Reset

Value

Description
