Freescale Semiconductor MPC5200B - Page 87

MPC5200B Users Guide, Rev. 1
2-42 Freescale Semiconductor
Pinout Tables
Pin PSC3_7 Ball B05
GPIO hi - z GPIO
Simple General Purpose I/O
USB2 hi - z USB2_SPEED
USB Speed
UART3 hi - z GPIO
Simple General Purpose I/O
UART3e hi - z GPIO
Simple General Purpose I/O
CODEC3 hi - z GPIO
Simple General Purpose I/O
CODEC3_w/MCLK hi - z GPIO
Simple General Purpose I/O
SPI hi - z SPI_MISO
SPI Master In Slave Out
UART3, SPI hi - z SPI_MISO
SPI Master In Slave Out
UART3e, SPI hi - z SPI_MISO
SPI Master In Slave Out
CODEC3, SPI hi - z SPI_MISO
SPI Master In Slave Out
Pin PSC3_8 Ball A05
GPIO hi - z GPIO
Simple General Purpose I/O
USB_2 hi - z USB2_SUSPEND
USB Susupend
UART3 hi - z INTERRUPT
UART3e hi - z INTERRUPT
CODEC3 hi - z INTERRUPT
CODEC3_w/MCLK hi - z INTERRUPT
SPI hi - z SPI_SS
SPI Slave Select
UART_3, SPI hi - z SPI_SS
SPI Slave Select
UART3e, SPI hi - z SPI_SS
SPI Slave Select
CODEC3, SPI hi - z SPI_SS
SPI Slave Select
Table 2-15. PSC3 Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
