MPC5200B Users Guide, Rev. 1
2-44 Freescale Semiconductor
Pinout Tables
Table 2-16. USB Pin Functions
Pin
Name
Dir.
Reset
Configuration
GPIO USB 2x UART4/5
USB_0 I/O GPIO USB1_OE GPIO
USB_1 I/O RST_CFG6 USB1_TXN UART4_RTS
USB_2 I/O RST_CFG7 USB1_TXP UART4_TXD
USB_3 I USB1_RXD UART4_RXD
USB_4 I USB1_RXP UART4_CTS
USB_5 I USB1_RXN UART5_RXD
USB_6 I/O GPIO USB1_PORTPWR UART5_TXD
USB_7 I/O GPIO USB1_SPEED UART5_RTS
USB_8 I/O GPIO USB1_SUSPEND UART5_CTS
USB_9 I/O INTERRUPT USB1_OVERCNT INTERRUPT
Table 2-17. USB Pin Functions by Pin
PIN / BALL NUMBER Function
Reset
Value
Description
Pin USB_0 Ball H01
GPIO hi - z GPIO
USB1 hi - z USB1_OE
RESET Config. hi - z ----
UART4, UART5 hi - z GPIO
Pin USB_1 Ball H02
GPIO hi - z ----
USB1 hi - z USB1_TXN
USB1 Transmit Negative
RESET Config. hi - z RST_CFG6 -- sys_pll_cfg_0
bit =0 : f
system
= 16x SYS_XTAL_IN
bit =1 : f
system
= 12x SYS_XTAL_IN
UART4, UART5 hi - z UART4_RTS
Pin USB_2 Ball H03
GPIO hi - z ----
USB1 hi - z USB1_TXP
USB1 Transmit Positive
RESET Config. hi - z RST_CFG7
(Pull bit low)
UART4, UART5 hi - z UART4_TXD
Uart Transmit Data
