Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-45
Pin USB_3 Ball G01
GPIO hi - z ----
USB1 hi - z USB1_RXD
USB1 Receive Data
RESET Config. hi - z ----
UART4, UART5 hi - z UART4_RXD
Uart Receive Data
Pin USB_4 Ball G02
GPIO hi - z ----
USB1 hi - z USB1_RXP
USB1 Receive Positive
RESET Config. hi - z ----
UART_, UART5 hi - z UART4_CTS
Uart Clear To Send
Pin USB_5 Ball G03
GPIO hi - z ----
USB1 hi - z USB1_RXN
USB1 Receive Negative
RESET Config. hi - z ----
UART4, UART5 hi - z UART5_RXD
Uart Recieve Data
Pin USB_6 Ball G04
GPIO hi - z GPIO
Simple General Purpose I/O
USB1 hi - z USB1_PRTPWR
USB Receive Negative
RESET Config. hi - z ----
UART4, UART5 hi - z UART5_TXD
Uart Transmit Data
Pin USB_7 Ball F01
GPIO hi - z GPIO
Simple General Purpose I/O
USB1 hi - z USB1_SPEED
USB Speed
RESET Config. hi - z ----
UART4, UART5 hi - z UART5_RTS
Uart Ready To Send
Pin USB_8 Ball F02
GPIO hi - z GPIO
Simple General Purpose I/O
USB1 hi - z USB1_SUSPEND
USB Suspend
RESET Config. hi - z ----
UART4, UART5 hi - z UART5_CTS
Uart Clear To Send
Table 2-17. USB Pin Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
