MPC5200B Users Guide, Rev. 1

2-50 Freescale Semiconductor

Pinout Tables

Pin ETH_1 Ball K02

GPIO hi - z GPIO

Simple General Purpose Output

USB2 hi - z GPIO

Simple General Purpose Output

ETH7 Wire hi - z ETH_TXD_0

Ethernet Transmit Data Output

ETH7 Wire / USB2 hi - z ETH_TXD_0

Ethernet Transmit Data Output

ETH18 Wire w/o MD hi - z ETH_TXD_0

Ethernet Transmit Data Output

ETH18 Wire w/ MD hi - z ETH_TXD_0

Ethernet Transmit Data Output

EHT7 Wire, UART4e, J1850 hi - z ETH_TXD_0

Ethernet Transmit Data Output

ETH7 Wire, J1850 hi - z ETH_TXD_0

Ethernet Transmit Data Output

UART_4, UART5e, J1850 hi - z UART5e_TXD

Uart Transmit Data

UART5e, J1850 hi - z UART5e_TXD

Uart Transmit Data

J1850 hi - z GPIO

Simple General Purpose Output

RESET Config. hi - z bit 15 -- large_flash_sel

bit = 0: Large Flash boot not enabled

bit = 1: Large Flash boot enabled.

Note 3.

Table 2-20. Ethernet Output Functions by Pin (continued)

PIN / BALL NUMBER Function

Reset

Value

Description
