Pinout Tables
MPC5200B Users Guide, Rev. 1
Freescale Semiconductor 2-51
Pin ETH_2 Ball K03
GPIO hi - z GPIO
Simple General Purpose Output
USB2 hi - z USB2_TXP
USB Transmit Positive
ETH7 Wire hi - z GPIO
Simple General Purpose Output
ETH7 Wire / USB2 hi - z USB2_TXP
USB Transmit Positive
ETH18 Wire w/o MD hi - z ETH_TXD_1
Ethernet Transmit Data Output
ETH18 Wire w/ MD hi - z ETH_TXD_1
Ethernet Transmit Data Output
EHT7 Wire, UART4e, J1850 hi - z GPIO
Simple General Purpose Output
ETH7 Wire, J1850 hi - z GPIO
Simple General Purpose Output
UART_4, UART5e, J1850 hi - z UART5e_RTS
Uart Transmit Data
UART5e, J1850 hi - z UART5e_RTS
Uart Transmit Data
J1850 hi - z GPIO
Simple General Purpose Output
RESET Config. hi - z bit 10 -- ppc_msrip PPC Boot Address / Exception
Table Loc.
bit = 0: 0000 0100 (hex)
bit = 1: fff0 0100 (hex)
Table 2-20. Ethernet Output Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
