MPC5200B Users Guide, Rev. 1
2-52 Freescale Semiconductor
Pinout Tables
Pin ETH_3 Ball J01
GPIO hi - z GPIO
Simple General Purpose Output
USB2 hi - z USB2_PrtPWR
USB Port Power
ETH7 Wire hi - z GPIO
Simple General Purpose Output
ETH7 Wire / USB2 hi - z USB2_PrtPWR
USB Port Power
ETH18 Wire w/o MD hi - z ETH_TXD_2
Ethernet Transmit Data Output
ETH18 Wire w/ MD hi - z ETH_TXD_2
Ethernet Transmit Data Output
EHT7 Wire, UART4e, J1850 hi - z UART_4_TXD
Uart Transmit Data
ETH7 Wire, J1850 hi - z GPIO
Simple General Purpose Output
UART_4, UART5e, J1850 hi - z UART_4_TXD
Uart Transmit Data
UART5e, J1850 hi - z GPIO
Simple General Purpose Output
J1850 hi - z GPIO
Simple General Purpose Output
RESET Config. hi - z bit 11 -- boot_rom_wait
bit = 0: 4 IPbus clocks of waitstate*
bit = 1: 48 IPbus clocks of waitstate*
Table 2-20. Ethernet Output Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
