Freescale Semiconductor MPC5200B

To Next Page

To Previous Page

Pinout Tables

MPC5200B Users Guide, Rev. 1

Freescale Semiconductor 2-53

Pin ETH_4 Ball J02

GPIO hi - z GPIO

Simple General Purpose Output

USB2 hi - z USB2_Speed

USB Speed

ETH7 Wire hi - z GPIO

Simple General Purpose Output

ETH7 Wire / USB2 hi - z USB2_Speed

USB Speed

ETH18 Wire w/o MD hi - z ETH_TXD_3

Ethernet Transmit Data Output

ETH18 Wire w/ MD hi - z ETH_TXD_3

Ethernet Transmit Data Output

EHT7 Wire, UART4e, J1850 hi - z J1850_TX

J1850 Transmit Data

ETH7 Wire, J1850 hi - z J1850_TX

J1850 Transmit Datat

UART_4, UART5e, J1850 hi - z J1850_TX

J1850 Transmit Data

UART5e, J1850 hi - z J1850_TX

J1850 Transmit Data

J1850 hi - z J1850_TX

J1850 Transmit Data

RESET Config. hi - z bit 12 -- boot_rom_swap

bit = 0: no byte lane swap - same endian ROM


bit = 1: byte lane swap - different endian ROM image

Table 2-20. Ethernet Output Functions by Pin (continued)

PIN / BALL NUMBER Function

Reset

Value

Description
