5 Scan

284

Scan

 List of Computers

Lists destination and URL.

Note •Select from among 5 kinds of processing methods (Scan to PC, Scan for Print to PC, Scan for E-mail

to PC, Scan for OCR to PC) in accordance with the intended use.

3 Press the <Start> button.

4 The scanned data will be forwarded to the specified destination.

Note •Select [Delete] to abort scanning.

5 Check the forwarded data on the destination computer.

Start

123

456

789

＃

<Start> button
