Fuji Xerox Versant 80 Press

To Next Page

To Previous Page

Print Overview

565

Printer Environment Settings

 Port 9100

Use Port9100 when the machine uses Port9100.

For more information on how to set up the machine using Port 9100, refer to "Installation When Using TCP/IP (LPD/Port

9100)" (P.568).

Supported Operating Systems

O: Available

Blank: Not available

* : The USB 2.0 Kit (optional) is required. And a USB 2.0 port is required on a computer to connect.

Connection method

Local

connection

Network connection

Port

USB2.0

LPD IPP Port9100

Protocol - TCP/IP TCP/IP TCP/IP

OS Windows XP O O O O

Windows Server 2003 O O O O

Windows Server 2008 O O O O

Windows Server 2012 O O O O

Windows Server 2012

OOOO

Windows Vista O O O O

Windows 7 O O O O

Windows 8 O O O O

Windows 8.1 O O O O
