Re-inserting the Staple Cartridge into the Cartridge Unit
911
Problem Solving
22
Re-inserting the Staple Cartridge into the Cartridge Unit
The following describes how to re-insert the staple cartridge to the unit when it has been
fallen off from its unit accidentally when the Finisher D4 or the Finisher D4 with Booklet or
the Finisher D5 is installed.
Note • The procedure is the same as when the staple cartridge is removed from the unit.
1 Open the cover of the unit as shown in the
figure, and remove the jammed staple.
2 See a lever on the rear side of the unit.
3 Move the lever in the direction of the arrow
shown in the figure.
Important • Be careful when removing jammed staples to
avoid hurting your fingers and nails.
4 Turn the unit upside while holding the lever,
and then take off the staple cartridge from its
unit.
Be careful in removing jammed
staples.
