Problem Solving

4 Move the handle [2b] upwards (1), turn the

knob [2c] to the left (2), and remove the

jammed paper.

5 Return the handle [2b] to its original position.

6 Close the front top cover of the High Capacity Stacker.

When the Lamp [E4] is Lit

1 Open the front top cover of the High Capacity

Stacker.

2 Move the handle [2a] downwards and remove

the jammed paper.

3 Return the handle [2a] to its original position.
