Paper Jams
861
Problem Solving
22
3 Remove the jammed paper.
Note • If paper is torn, check for any torn pieces of
paper inside the machine.
4 Close the top cover.
5 Gently put Tray 6 back into position.
Paper Jams in Tray 6
1 Pull out Tray 6.
2 Remove the jammed paper.
Note • If paper is torn, check for any torn pieces of
paper inside the machine.
3 Push the tray in gently until it stops.
Paper Jams in the HCF B1-S/High Capacity Feeder C3-DS
The following describes how to clear paper jams in the optional HCF B1-S (Tray 6) or High
Capacity Feeder C3-DS (Trays 6 and 7).
The following shows the reference for the procedure.
Paper Jams in Tray 5 (Bypass) ..................................................................................................................................................862
Paper Jams in Trays 6 and 7......................................................................................................................................................862
Paper Jams at the Handle [1a] and the Knob [1c] ..............................................................................................................863
Paper Jams at the Handle [1b] and the Knob [1c] ..............................................................................................................864
Paper Jams at the Handle [1d] and the Knob [1c] ..............................................................................................................864
Note • A remedy differs depending on where the paper jam occurs. Follow the instructions displayed and
remove the jammed paper.
When pulling out the paper
tray, do it slowly. If pulled out
with too much force, the tray
might hit and injure your knees.
To Next Page
