Fuji Xerox Versant 80 Press

Paper Jams
889
Problem Solving
22
2 Move the handle [1b] upwards, turn the knob
[1a] to the left, and remove the jammed paper.
3 Return the handle [1b] to its original position.
4 Close the front top cover of the High Capacity Stacker.
When the Lamp [E3] is Lit
1 Open the front top cover of the High Capacity
Stacker.
2 Move the handle [1b] upwards (1), turn the
knob [1a] to the left (2), and remove the
jammed paper.
3 Return the handle [1b] to its original position.
