19 Machine Status

636

Machine Status

2 Select the [Billing Information] tab.

3 Select [User Account Billing Information].

4 Select a meter to check.

Note •The meters are displayed only for the

features set to [Enable Accounting] in the

Auditron mode.

 Meter (Copy Jobs)

Displays the number of pages copied.

 Meter (Scan Jobs)

Displays the number of pages scanned.

 Meter (Print Jobs)

Displays the number of pages printed.

Note •[Meter (Print Jobs)] is not displayed for the system administrator.
