Replacing Consumables

669

Maintenance

2 Hold the handle [R1] at the position shown in

the figure.

3 Pull out the unit.

4 Hold the tab of the staple cartridge to remove

it from the unit in the direction of the arrow as

shown in the figure.

5 Push a new staple cartridge into the unit.

6 Push the removed unit back to the original

position.

7 Close the finisher right door.

Note • A message will be displayed and the machine will not operate if the finisher right door is even

slightly open.
