Fuji Xerox Versant 80 Press

To Next Page

To Previous Page

Replacing Consumables

677

Maintenance

1 Make sure that the machine has stopped, and

pull out the trimmer waste container slowly.

2 Hold the trimmer waste container by its belt,

and pull out the container with both hands.

3 Discard all the scraps.

4 Insert the empty trimmer waste container all

the way into the machine.
