Interface Cables
69
Product Overview
2
4 Press the main power switch to the [ ] position to switch off the main power.
5 Connect the network cable to the Ethernet interface connector.
Note •Always use the correct network cable with your network connection. When you replace the cable,
contact our Customer Support Center.
z
When the Secondary Ethernet (optional) is
not installed
Note •To use the connector as 1000BASE-T, the
Gigabit Ethernet (optional) is required.
z
When the Secondary Ethernet (optional) is
installed
Note •The Secondary Ethernet connector supports
1000BASE-T only.
• To use the standard Ethernet connector as
1000BASE-T, the Gigabit Ethernet (optional)
is required.
6 Press the main power switch to the [ | ] position
to switch on the main power.
7 Close the machine front door.
8 Press the power switch to switch on the power.
For more information on setting items, refer to "Printer Environment Settings" (P.563).
To Next Page
