Manual Alignment Adjustment
703
Maintenance
21
3 Enter a value by adding the difference X measured in step 1 to the current setting values of
[Side 1] and [Side 2] of [X Print Position].
Enter a value by adding the difference Y measured in step 1 to the current setting values of
[Side 1] and [Side 2] of [Y Print Position].
Note • [X Print Position]: Specify a positive value to move the position of the image in the opposite direction
of the paper feed direction, and a negative value to move the position of the image in the paper
feed direction.
• [Y Print Position]: Specify a negative value to
move the image toward the front of the
machine, or a positive value to move the
image toward the rear of the machine.
4 Select [Save].
