Paper Jams
867
Problem Solving
22
Note • A remedy differs depending on where the paper jam occurs. Follow the instructions displayed and
remove the jammed paper.
Paper Jams at the Handle [1c]
1
Make sure that the machine has stopped, and
open the Transport Unit V1 front door.
2 Move the handle [1c] to the right (1), and turn
the knob [1b] to the right (2).
3 Remove the jammed paper.
Note • If paper is torn, check for any torn pieces of
paper inside the machine.
4 Return the handle [1c] to its original position.
5 Close the Transport Unit V1 front door.
Note • A message will be displayed and the machine will not operate if the Transport Unit V1 front door is
even slightly open.
Paper Jams at the Handle [1a]
1
Make sure that the machine has stopped, and
open the Transport Unit V1 front door.
