Fuji Xerox Versant 80 Press

To Next Page

To Previous Page

23 Appendix

976

Appendix

 Document: Auto, Coordinate Origin: 0 Degrees, Scaling Mode: Paper Size, Scaling: ON

 Document: Auto, Coordinate Origin: 0 Degrees, Scaling Mode: Paper Size, Scaling: OFF

 Document: Auto, Coordinate Origin: 0 Degrees, Scaling Mode: Active Coordinate Area,

Scaling: ON

Print Area

Document Size Paper Size

Print Area

Document Size

Paper Size

Print Area

Active Coordinate Area determined by

entered data

Paper Size
