Connect the SAS cable to the corresponding HDD backplane.
For the cable plan, see "Appendix B" on page 363.
Example SAS CP5xxi
Figure 145: Connecting cables - SAS CP5xxi
▶
Connect the following cables:
Expansion cards and backup units
