Fujitsu PRIMERGY RX1330 M5 User Manual

Note on network settings recovery
When replacing network controllers, network configuration settings in
the OS will be lost and replaced by default values. This applies to all
static IP address and LAN teaming configurations.
Ensure to note down your current network settings before replacing a
network controller.
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
If applicable, "Removing the front cover with lock" on page 45.
▶
If applicable, "Configuring LAN teaming" on page 92.
▶
"Suspending BitLocker functionality" on page 69.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 49.
▶
"Locating the defective component" on page 44.
▶
Remove the corresponding riser module, see "Removing a riser module" on
page 63.
Removing the defective expansion card
▶
Remove the expansion card, see "Removing the expansion card" on
page 201.
▶
If the slot bracket on the defective expansion card is to be reused, remove it
from the expansion card, see "Removing a slot bracket" on page 184.
Installing the new expansion card
▶
If applicable, install the slot bracket, see "Installing a slot bracket" on
page 183.
▶
Install the expansion card, see "Installing the expansion card" on page 196.
Expansion cards and backup units
RX1330 M5 Upgrade and Maintenance Manual 203

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
