Fujitsu PRIMERGY RX1330 M5

Installing the new front USB
Figure 227: Installing the front USB connector
▶
Insert the new front USB cable from the inside of the server.
▶
Push the front USB connector into the recess at the front panel.
▶
Fasten the front USB connector with the two screws (see circles).
Front panel
280 Upgrade and Maintenance Manual RX1330 M5
