Fujitsu PRIMERGY RX1330 M5 User Manual

Tools: Removing the system board:
– Phillips PH2 / (+) No. 2 screw driver
Removing the TPM:
–
Bit screw driver
– flat nose pliers
–
TPM bit insert
(*)
(*)
For Japan:
– TPM module fixing tool (S26361-F3552-L909)
CAUTION
▶
Advise your contact persons that they must provide you with all
recovery keys which belong to the system to restore them in the
TPM later.
Preliminary steps
Preliminary steps are not necessary, if a system board has to be
replaced and the TPM is used again.
▶
Before removing the TPM board, remove the BitLocker protection and
decrypt the volume, see "Removing BitLocker protection and decrypting the
volume" on page 300
.
▶
Disable the TPM in the system board BIOS, see "Disabling the TPM in the
system board BIOS" on page 300.
▶
"Suspending BitLocker functionality" on page 69.
▶
If applicable, "Removing the front cover with lock" on page 45.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
Remove all PSUs, see "Removing a hot-plug PSU" on page 105.
▶
"Getting access to the component" on page 49.
▶
Remove the air duct, see "Removing the air duct" on page 65.
System board and components
RX1330 M5 Upgrade and Maintenance Manual 299

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
