Fujitsu PRIMERGY RX1330 M5 User Manual

▶
Remove all fan modules, see "Removing the defective fan module" on
page 175.
▶
Remove all riser modules, see "Removing a riser module" on page 63
.
▶
Remove the system board, see "Removing the defective system board" on
page 330.
Removing BitLocker protection and decrypting the volume
▶
Before removing the TPM board, it is necessary to remove BitLocker
protection from the computer and to decrypt the volume. Ask the system
administrator to turn off BitLocker protection using the BitLocker setup
wizard available either from the Control Panel or Windows Explorer:
▶
Open Bitlocker Drive Encryption by clicking the Start button, clicking
Control Panel, clicking Security, and then clicking Bitlocker Drive
Encryption.
Administrator permission required: If you are prompted for an
administrator password or confirmation, type the password or
provide confirmation.
▶
T
o turn of
f BitLocker and decrypt the volume, click Turn Off BitLocker,
and then click Decrypt the volume.
Decrypting the volume may be time-consuming. By decrypting the
volume, all of the information stored on that computer is decrypted.
For more information on how to disable BitLocker drive encryption,
see the Microsoft Knowledge Base. See the Fujitsu web pages for
more details.
Disabling the TPM in the system board BIOS
Proceed as follows:
▶
Switch on or restart your server.
▶
As soon as the startup screen appears, press the
[F2] function key to enter
the BIOS setup menu.
▶
Select the Advanced menu.
▶
Select the Trusted Computing submenu.
System board and components
300 Upgrade and Maintenance Manual RX1330 M5

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
