Fujitsu PRIMERGY RX1330 M5 User Manual

▶
"Removing the air duct" on page 65
.
Replacing the microSD card
▶
Remove the Dual microSD 64GB Enterprise, see "Removing the Dual
microSD 64GB Enterprise" on page 323.
▶
Remove the defective microSD card from the Dual microSD 64GB
Enterprise.
Proceed as described in the following:
▶
To eject the defective microSD card, gently push it in and then let go.
▶
Pull the microSD card straight out of its slot.
CAUTION
(not valid for Europe, Middle East, India and Africa)
The microSD card contains customer information.
▶
After removing the microSD card, hand the card over to the
customer.
▶
If the customer requests disposal of the defective microSD
card, proceed as follows: Using a pair of side-cutting pliers,
cut the microSD card in half.
▶
Install the new microSD card on the Dual microSD 64GB Enterprise.
Proceed as described in the following:
▶
With the label facing up, insert the microSD card into the microSD slot on
the controller until it locks in place.
▶
Install the Dual microSD 64GB Enterprise, see "Installing the Dual microSD
64GB Enterprise" on page 320
.
Concluding steps
▶
"Installing the air duct" on page 66.
▶
"Reassembling" on page 53.
▶
"Connecting the power cord" on page 57.
▶
"Switching on the server" on page 60.
▶
If applicable, "Installing the front cover with lock" on page 61.
System board and components
RX1330 M5 Upgrade and Maintenance Manual 327
