16.2.3.2 ID, CSS and Global Error indicators
Figure 280: ID, CSS and Global Error indicators
1 ID indicator
2
Global Error indicator
3
CSS indicator
For more information on detected errors, see the System Event Log or
use the iRMC S6 web interface.
ID indicator (1)
See also "iRMC-related status signals" on page 356.
Status Description
blue on The server has been highlighted using the iRMC S6
web interface or the ID button on the front panel for
easy identification.
flashing blue
The server has been highlighted for easy identification
using the iRMC S6 (A
VR) with disabled local VGA
output.
Global Error indicator (2)
See also "iRMC-related status signals" on page 356.
Status Description
off No critical event detected (non-CSS component).
orange on Prefailure event detected (non-CSS component).
Appendix A
RX1330 M5 Upgrade and Maintenance Manual 355
