The minimum startup configuration consists of the following components and
cables:
Component Notes
System board no TPM or expansion cards installed
1 CPU with CPU heat
sink
installed in CPU slot CPU 1
1 memory module installed in DIMM slot 1A
Common Operation
Panel (COP)
1 PSU installed in PSU bay PSU 1
Table 4: Minimum startup configuration - components
Cable Notes
Front panel cable
Power cable
Table 5: Minimum startup configuration - cables
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page
47.
▶
Take the system down to its minimum startup configuration.
▶
"Connecting the power cord" on page 57.
▶
Connect a display to the server.
▶
Switch on the server, see "Switching on the server" on page 60.
CAUTION
▶
Since the fan module is not included in the minimum startup
configuration, the server must be shut down immediately after the
diagnostic process is complete (POST phase has been passed).
▶
The minimum startup configuration must be used exclusively for
diagnostic purposes by maintenance personnel, never in daily
operation!
Appendix A
RX1330 M5 Upgrade and Maintenance Manual 361

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
