Chapter 4 - Functional Checks 4-29
4-4-8 Calculations
The Voluson® P8 / Voluson® P6 system supports calculation packages and application-oriented
patient Worksheets (Reports) for following applications:
• Abdomen Calculations
• Small Parts Calculations
• Obstetric Calculations
• Cardiology Calculations
• Urology Calculations
• Vascular Calculations
• Gynecology Calculations
• Pediatric Calculations
• Neurology Calculations
• Musculoskeletal Calculations
NOTE: Confirm that the patient information is correct and the probe and application are selected properly.
NOTE: Different menus are displayed depending on:
• the currently chosen Application
• the selected Display Mode,
• the selected “Study”,
• and the settings in the Measure Setup -
MEASURE & CALC page.
For further details refer to the Voluson® P8 / Voluson® P6 Basic User Manual, Chapter 11
General remarks to perform Calculations:
By pressing the MEASURE
key (toggle between "Generic meas. menu" and "Calc. meas.
• menu") on the control panel the Calculation function is switched on.
• Positioning of measurement marks is done with the TRACKBALL
.
• Entering and storage of measuring marks is done with SET
(right or left trackball key).
• To change measuring marks before completion press CHANGE
(upper trackball key).
• Depending on the setting in the Measure Setup, also the FREEZE
key can be used for confirming
the last measuring mark of the currently performed measurement.
• The status bar area shows the current function of the trackball.
• To cancel the measurement of the currently selected item, select CANCEL
on the Voluson® P8 /
Voluson® P6.
• To delete the results of the last measured item, select DELETE LAST
on the Voluson® P8 /
Voluson® P6.
• To delete all measurement results of the selected “Study” from the monitor as well as from the
corresponding Worksheet, select the CLEAR STUDY
key on the Voluson® P8 / Voluson® P6.
• All measurement results will be automatically included in the corresponding patient worksheet.
• To erase measurement results from the screen, press the CLEAR
key on the control panel or press
the DEL
key on the keyboard.
• To exit from Calculations select the EXIT
key on the Voluson® P8 / Voluson® P6, press the CALC
key or press the EXIT
key on the control panel.
