5-18 Section 5-2 - General Information
5-2-5 Description of Hardware Options
5-2-5-1 CW - Continuous Wave Doppler
CW Doppler mode provides real time spectral analysis of CW Doppler signals. This information
describes the Doppler shifted signal from the moving reflectors in the CW Doppler beam. CW Doppler
can be referenced through a small pencil probe or phased array scan head, but it can also be used in
conjunction with a 2D image which has an M-line superimposed on the 2D image indicating the position
of the Doppler sample volume. For through-the-beamformer CW, this beam is steerable by the operator,
and is done by adjusting the location of the M-line. The CW Doppler beam, or M-mode line, can be
steered allowing interrogation along an operator-selected line within the image.
NOTE: This feature is available only on Voluson P8 systems.
5-2-5-2 DVR Recorder
For details see: Section 5-9-1-1 "DVD Recorder" on page 5-37
5-2-5-3 ECG Module
For details see: Section 5-9-4 "ECG Module" on page 5-37
5-2-5-4 Wireless Network Adapter (WLAN - Wireless Local Area Network)
For details see: Section 5-9-5 "Wireless Network Adapter" on page 5-37
5-2-6 Data Location
The Voluson® P8 / Voluson® P6 has a 160 Gbyte Hard disk divided into 4 partitions:
C: System partition:
- Operating System (Windows XP) including all Windows settings (IP-address, Network Name,
etc.)
- US-Application Software (UISAPP)
- Global Service Platform Software
- Software Options
D: User partition:
- User Presets (Backup) database
- Images (Archive), Patient-ID´s and Reports database
- Service database
- System settings database
R: Rescue partition:
- Factory Images of C:Partition for System recovery after HDD (Windows) crash
Table 5-3 Hardware Options
HW-Options Description
1
CW-Doppler
5-2-5-1 CW - Continuous Wave Doppler
2
DVR Recorder
5-2-5-2 DVR Recorder
3
ECG Module
5-2-5-3 ECG Module
4
WLAN Network Adapter
5-2-5-4 Wireless Network Adapter (WLAN - Wireless Local Area Network)
