8-84 Section 8-39 - Replacement of FULL AN KEY

Section 8-39

Replacement of FULL AN KEY

8-39-1 Manpower

One person, 30 minutes

8-39-2 Tools

Philips screwdriver

8-39-3 Removal Procedure

1.) Remove 9 screws.

Figure 8-100 removing 9 screws
