5-26 Section 5-4 - BackEnd Processor
Table 5-5 Voluson® P8 / Voluson® P6 - RFS components
5-4-1 Hard Disk Drive
The Hard Disk is the main storage device of the Voluson® P8 / Voluson® P6.
The Voluson® P8 / Voluson® P6 160 Gbyte Hard disk, which is controlled by the CPU via signals from
SATA, is divided into 4 partitions.
For further details see: Section 5-2-6 "Data Location" on page 5-18.
5-4-2 SOM (System On Module)
5-4-2-1 Congatec
Built in or external Components:
- On Board VGA, LAN, USB 2.0, Sound
- CPU: Intel
®
Core
TM
2 Duo Processor T9400, 2.53 GHz
Major Tasks:
- System Control
- 2D- / 3D- / 4D- Image processing and Rendering
Sub-section Description Page Number
5-4-1
Hard Disk Drive
5-26
5-4-2
SOM (System On Module)
5-26
5-4-3
DVR - Digital Video Recorder (option)
5-27
