GE HEALTHCARERAFT VOLUSON® P8 / VOLUSON® P6

DIRECTION 5459672-100, R

EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL

8-80 Section 8-36 - Replacement of the DVD

3.) Unscrewing 2 screws to remove the DVD .

8-36-5 Installation Procedure

1.) Install the new parts in the reverse order of removal.

2.) Perform: FRU8-37: Replacement of the DVD - Functional Tests..

Figure 8-96 Removing the DVD
