3-30 Section 3-7 - Printer Installation
Section 3-7
Printer Installation
NOTE: For Connection schemes refer to Section 3-5 "Connection of Auxiliary Devices" on page 3-10.
For further installation instructions see:
• Section 3-7-1 "Installing Digital Black & White Printer Sony UP-D897" on page 3-30
• Section 3-7-2 "Installing Digital Color Printer Sony UP-D25MD" on page 3-30
• Section 3-7-3 "Installing the Bluetooth Deskjet Printer" on page 3-31
• Section 3-7-4 "Printer Installation manually" on page 3-42
3-7-1 Installing Digital Black & White Printer Sony UP-D897
1.) Power off/Shutdown the system as described in: Section 3-6-3 on page 3-27.
2.) Connect the printer as described on page 3-12.
3-7-2 Installing Digital Color Printer Sony UP-D25MD
1.) Power off/Shutdown the system as described in: Section 3-6-3 on page 3-27.
2.) Connect the printer as described on page 3-14.
CAUTION
!! CAUTION:
The Bluetooth Printer Connection set as well as the Color Deskjet printer MUST NOT be installed
by the user!
For installation please contact your local distributor or GE service representative.
NOTICE
!! NOTICE:
After boot up of the system, verify the correct settings in the printer “Properties”,
see: Section 3-7-5 "Adjustment of Printer Settings" on page 3-46.
Afterwards assign the Printer to the remote keys P1
, P2, and P3/DVR
see: Section 3-7-6 "Remote Control Selection" on page 3-53.
NOTICE
!! NOTICE:
After boot up of the system, verify the correct settings in the printer “Properties”,
see: Section 3-7-5 "Adjustment of Printer Settings" on page 3-46.
Afterwards assign the Printer to the remote keys P1
, P2, and/or P3/DVR
see: Section 3-7-6 "Remote Control Selection" on page 3-53.
