GE HEALTHCAREDRAFT VOLUSON® P8 / VOLUSON® P6

DIRECTION 5459672-100, R

EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL

Chapter 5 - Components and Functions (Theory) 5-19

- Printer Drivers

LINUX partition: (not visible in Windows)

- Linux operating system for rescue functionality

Figure 5-5 Data Location - distribution of partitions
