GE HEALTHCAREDRAFT VOLUSON® P8 / VOLUSON® P6

DIRECTION 5459672-100, R

EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL

Chapter 5 - Components and Functions (Theory) 5-43

NOTE: All DC-supply voltages for built in peripherals are generated in DCDC module not inside ACFE.

NOTICE

!! NOTICE:

The systems mains supply input voltage is a free voltage not need to configure for different AC power-

in.
