GE HEALTHCAREDRAFT VOLUSON® P8 / VOLUSON® P6
DIRECTION 5459672-100, R
EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL
Chapter 10 - Care & Maintenance 10-33
ELECTRICAL SAFETY
Outlet and Ground Continuity test
Earth leakage current test
Enclosure leakage current test
Outlet/Ground Continuity
Max Value
Allowed
Value
Measured
OK? Comments
Outlet (correct ground &wiring
config.)
N/A N/A
System Ground Continuity 0.2 Ohm
Tester Neutral
Tester
Polarity
Switch
Max Value Allowed
Value
Measured
OK? Comments
Enter Name of tested peripheral here:
Closed Normal 0.3mA(USA)/0.5mA(Others)
Closed Reversed 0.3mA(USA)/0.5mA(Others)
Open Normal 1mA
Open Reversed 1mA
Tester
Neutral
Tester
Polarity
Switch
Protective
Earth
Switch
Max Value Allowed
Test 1
Wheel
Test 2
LCD
Optional
Test 3
Optional
Test 4
OK? Comments
Enter Name of tested peripheral here:
Closed Normal Closed
0.1mA(USA)/
0.1mA(Others)
Closed Normal Open
0.3mA(USA)/
0.5mA(Others)
Closed Reversed Closed
0.1mA(USA)/
0.1mA(Others)
Closed Reversed Open
0.3mA(USA)/
0.5mA(Others)
Open Normal Closed
0.5mA(USA)/
0.5mA(Others)
Open Reversed Closed
0.5mA(USA)/
0.5mA(Others)
