3-6 Section 3-3 - Receiving and Unpacking the Equipment

Remove the top cover and top plate.

Remove the three Plastic Joints from the outer sleeve..

Remove the outer sleeve and the monitor cushion

Table 3-5 Unpacking Procedure
