1•20 Quick Guide
Play All Songs
Use the PLAY ALL SONGS button (located under the DISK button to the right of
the display) to play all the Songs or MidiFiles directly from a disk. No need to
enter Disk mode; just insert the disk and press PLAY ALL SONGS.
1. Insert a PS Songs disk or MidiFile data disk into the drive.
Check the disk label for the type of data contained on the disk.
2. Press the PLAY ALL SONGS button.
The message “Wait!!” appears for a few seconds and the PS1000 starts to
scan the disk contents. Shortly after a Song starts to play back and the
display shows the name of the Song.
When the first Song or MidiFile ends, a second sequence begins.
Playback continues non-stop until all the Songs or MidiFiles on disk have
been played. When the last Song or MidiFile reaches the end, playback
stops automatically.
3. You can stop the playback at any time by pressing the PLAY/STOP or
START/STOP buttons.
Playback stops instantly.
Song Play - Direct from Disk
In addition to the PLAY ALL SONGS feature, PS1000 also allows you to play a
preselected Song or MidiFile directly from disk, particularly useful for Song files
that are larger than the available sequencer memory.
The Demo disk supplied with PS1000 contains a Song file, but if you have a
Standard MIDI File data disk, you can use this instead of the supplied disk.
1. After inserting the disk into the disk drive, press the DISK button and use
the TEMPO/DATA / buttons to select a Song or MidiFile.
Songs are identified by a short name while Midifiles show a name together
with the “Mid” extension.
2. After selecting the Song or MidiFile, press PLAY/STOP or START/STOP
to start the playback directly from Disk.
The message “Wait!!” appears for a few seconds then the name of the cur-
rent Song is shown in the display. Shortly after, PS1000 enters Song mode
and playback begins.
3. To stop the playback at any time, press PLAY/STOP or START/STOP.
PS1000 exits Disk mode and returns to the mode selected before pressing
DISK. Don’t forget to remove the Floppy disk from the drive.
Note: How to load Songs to memory is ex-
plained in the Disk chapter.
