P a g e | 279

UCM6200 Series User Manual

• Never: Whenever ringing occurs, the UCM6200 will send 180 Ringing as long

as 200OK has not been set yet. Inband ringing will not be generated even the

end point device is not working properly.

Server User Agent

Configure the user agent string for the UCM6200.

Send Compact SIP

Headers

If enabled, compact SIP headers will be sent. The default setting is "No".
