Hillrom Centrella Smart+ Bed - Removable IV Pole (P2217); Permanent IV Pole (P7511)

Accessories
Centrella® Smart+ Bed Instructions for Use Manual (193587 REV 10) 117
Removable IV Pole (P2217)
Permanent IV Pole (P7511)
• Warning—Correctly attach the IV pole; otherwise, it may
fall.
• Warning—Uneven loading of the IV pole could cause the
contents to fall.
• Warning—When you lower the upper section of an IV
pole, always hold the upper section of the pole before
you pull the release knob.
• Warning—Install the IV pole in an equipment socket only
(see “Equipment Sockets” on page 21).
The IV pole is a removable, telescopic pole that installs in any of the equipment sockets.
To Install
Insert the IV pole vertically into any of the equipment sockets at either the head end or foot end of the
bed.
To Remove
Pull the IV pole out from the equipment socket.
To Use
1. Lift the IV pole from its stored position behind the headboard and raise the pole straight up.
2. Make sure that the pole drops into the locked position.
3. Raise the upper section of the pole to the desired height.
To Store
1. Hold the upper section of the IV pole. Push the upper collar down, and lower the upper pole
section into the lower pole section.
2. Lift the lower section of the IV pole up, and lower the pole down to the stored position behind the
headboard.
