Bed Frame Features
20 Centrella® Smart+ Bed Instructions for Use (193587 REV 10)
HEADBOARD
FOOTBOARD
Warning—When the footboard is removed from the bed, do not lay the footboard flat on the floor.
Store the footboard in a position or location so that it does not come in contact with biohazards or
cause a tripping hazard. Failure to do so may cause injury or equipment damage.
Caution—Do not exceed the 55 lb (25 kg) load capacity (safe working load) of the footboard. To do so
could cause equipment damage.
When the unit is connected to AC power, and you release the brake, these will occur to let you know
that the brake is not set:
• The Brake Not Set alert will sound.
• The alert indicator on the caregiver control panel will
show.
• A message will show on the touchscreen.
• Beds equipped with Voice Alerts will alert “Brake not
set.”
To address the alert, either unplug the unit (for transport) or
set the brake.
The headboard attaches to the head end of the frame.
The headboard can be removed for increased access to the patient’s head.
A caregiver can quickly remove or attach the headboard in a single step
without the use of tools.
To Remove
1. Remove any cords from the headboard.
2. Lift the headboard straight up.
To Install
Align the headboard pins with the sockets in the frame, and then lower the headboard into the
sockets. Push the headboard down until the bottom rests on the frame.
The footboard attaches to the articulating foot section, and it remains
perpendicular to the surface of the foot section at all times.
A caregiver can quickly remove or attach the footboard in a single step
without the use of tools.
To Remove
1. Remove any cords from the footboard.
2. Lift the footboard straight up.
