Hillrom Centrella Smart+ Bed - Foot-End Safeview+ Alerts Option; Experience Pod (Overhead Arm) Device Option; Other

Symbols
Centrella® Smart+ Bed Instructions for Use (193587 REV 10) 11
Foot-End SafeView®+ Alerts Option
Bed Exit Alert—OFF
indicator (page 26)
Siderail position indi-
cator (page 26)
Bed Exit Alert—ON or
SILENCE indicator
(page 26)
Bed in the lowest posi-
tion indicator (page
26)
Heart rate or Respira-
tion rate (HR/RR)
Alarm—ON or SILENCE
indicator (page 26)
WatchCare® Alert—On
or SILENCE indicator
(page 26)
Experience Pod® (overhead arm) Device Option
Steps to remove the
overhead arm (page
27)
Transport position of
the overhead arm
(page 27)
Steps to remove the
P7926A07 overhead
arm (page 27)
Watch doors and walls
during transport with
an overhead arm
(page 27)
Do not allow the
patient to use the over-
head arm to assist
them to get out of bed
(page 27)
Overhead arm light
location (page 27)
Other
WARNING (yellow and
black)
(Bed and patient pen-
dant only) According
to IEC 60529, Rating
for protection against
fluid ingress and iden-
tified as equipment
that is protected
against spraying and
splashing water
CAUTION (white and
black)
Type B applied part
according to
IEC 60601-1
Symbol Description Symbol Description
